Kemapower 12.8V 100ah LiFePO4 Battery for 12V System with BMS System and Cell Equalizer Inside Lithium Battery

Basic Info.

Model NO.	LFP-ABS
Size	Large
Product Name	Lifep04 Battery LFP-ABS
Cycle Life	6000 Times
Nominal Voltage	12V
Transport Package	Seaworthy Packing
Specification	50-300
Trademark	KEMAPOWER
Origin	China
HS Code	8507600090
Production Capacity	50000PCS/Yer

Packaging & Delivery

Package Size 101.00cm * 90.00cm * 70.00cm Package Gross Weight 0.700kg

Product Description

PRODUCT DESCRIPTION

KEY FEATURES
1. 12VDC Deep Cycle Energy storage Lead-acid alternative LiFePo4 lithium battery
2. Capacity 12.8VDC 6Ah,10Ah,12Ah,18AH,20AH,36AH,50Ah,100AH,200AH
3. 6000 Cycle life(80% [email protected] ºC), 10 times more than AGM battery
4. Discharge DOD over 95%, 25-50% more than AGM battery
5. Compact Size and light weight , > 50% smaller and lighter than AGM battery
6. Wide Compatibility, Cooperate With Most Inverters
7. Embedded BMS , Full protection and Balance charge discharge
8. LCD Display option
9. Bluetooth communication option
10. Max 4 series connection option

TECHNICAL SPECIFICATIONS

MODE		LFP12006-ABS	LFP12010-ABS	LFP12012-ABS	LFP12018-ABS	LFP12020-ABS	LFP12036-ABS	LFP12050-ABS	LFP12100-ABS	LFP12200-ABS
Battery Pack Module	Rated Voltage	12.8VDC	12.8VDC	12.8VDC	12.8VDC	12.8VDC	12.8VDC	12.8VDC	12.8VDC	12.8VDC
	Rated Capacity Ah/WH	6AH	10AH	12AH	18AH	20AH	36AH	50AH	100AH	200AH
	Rated Energy	76.8WH	128WH	153.6WH	230.4WH	256WH	460.8WH	640WH	1280WH	2560WH
Battery Pack Charge/Discharge(Customizable)	Recommended Charge Current	≤6A	≤6A	≤12A	≤20A	≤20A	≤30A	≤20A	≤20A	≤40A
	Max. Continue Charge Current	6A	10A	12A	18A	20A	36A	50A	100A	200A
	Recommended Charge Voltage	14.1V	14.1V	14.1V	14.1V	14.1V	14.1V	14.1V	14.1V	14.1V
	Recommended Discharge Current	3A	5A	6A	9A	10A	18A	25A	50A	100A
	Max. Continue Discharge Current	6AMP	10AMP	12AMP	18AMP	20AMP	36AMP	50AMP	100AMP	200AMP
	Recommended Over Discharge Voltage	11.2V	11.2V	11.2V	11.2V	11.2V	11.2V	11.2V	11.2V	11.2V
Product Size ( Around mm) Customizable		101*90*70	151*65*94	151*98*95	181*77*167	181*77*167	198*166*170	229*138*208	330*173*220	522*240*218
Product Weight ( Around Kg)		0.7kg	1.2kg	1.4kg	2.1kg	2.3kg	3.3kg	6kg	12.5kg	25kg
